·         2-inch, fiberglass inside/outside copper voice coil

·         1600W continuous program power handling

·         94 dB Sensitivity

·         30 Hz – 6000Hz  Frequency  range

·         Copper  demodulation ring

·         Forced air ventilation and 14mm top plate for minimum power compression

·         Dual spider design with silicon based dampening control

·         Double-roll surround and corrugated straight cone geometry

·         Nominal Diameter: 258/10 mm/inch

·         Rated Impedance: 8 Ω

·         Program Power:300 W AES

·         Power handling capacity: 150W RMS

·         Sensitivity: 94 dB

·         Frequency Range: 30 Hz -6000 Hz

·         Minimum Impedance: 6.2 Ω

·         Voice Coil Diameter: 51 / 2 mm/inch

·         Voice Coil Material: Copper

·         Voice Coil Winding Depth: 16 / 0.6 mm/inch

·         Number of layers: 1

·         Kind of layer:  outside

·         Cone Material: No pressed pulp

·         Cone Design:Straight

·         Surround Material: Polycotton

·         Surround Design:Double roll

·         Fs:  33 Hz

·         Re: 5.2 Ω

·         Qes : 0.32

·         Qms: 6.2

·         Qts: 0.3

·         Vas: 66 dm³

·         Sd:  345 dm3

·         Xmax:  5.5 mm

·         Mms: 46 g

·         BL: 12.5 N/A

·         Cms: 0.48 mm/N

·         Overall Diameter: 258/10 mm/inch

·         Bolt Circle Diameter: 258 / 10 mm/inch

·         Bolt Hole Diameter: 6 / 0.3 mm/inch

·         Front Mount Baffle Cut-out: 249 /9.8  mm/inch

·         Depth: 130 /5.1 mm/inch

·         Net Weight: 3 kgs

·         Shipping weight: 6*3 kgs

·         Packing Size: 265*265*140 mm
